Industrial cnc lathe machine oil mist collector Purification Efficiency 99% oil mist separator for cnc machine tools

Large air volume and low energy consumption
No consumables required
High efficiency purification
factory prices
Customization available

Applicable fields:
Collection and purification of oil mist and oil mist produced in the processing of machining centers, CNC lathes, cleaning equipment, cold forging machines, corers, grinders, etc.

FEATURE
Large air volume and low energy consumption
· Equipped with high efficiency fan, large air volume can be realized
with low energy consumption
Small size and light weight
· We use centrifugal structure design, so the machine is small and light
· The installation space is saved and the installation is more convenient.
Combination of centrifugal and filter
· The filter cotton further improves the filtering accuracy and efficiency
of the centrifugal structure
· According to the demand, two different after-filters can be selected to
achieve higher filtering effect
WORKING PRINCIPLE
The air containing oil mist is sucked into the oil mist collector and filtered through the following three steps. · First,centrifugal separation. Driven by the high-speed rotating impeller, the rotating airflow spirals upward, and the oil mist particles are thrown to the inner wall of the machine by centrifugal force to achieve separation.
·Secondly, filtered through multiple layers of filter. ·Finally, filtered again through a high-efficiency filter Suitable
high-efficiency filters are selected for different working conditions of oil mist, which can effectively purify the smog of 0.3 micron level.
